XCMG 50 ton heavy folding truck jib crane QY50KA

XCMG truck jib crane QY50KA

  • QY50KA
  • XCMG
Quantity:

Description:

QY50KA is 50 ton XCMG truck jib crane, it is with XCMG designed and produced truck chassis with full wide cab, drive/steer is 8X4X4.

It is with 5 section boom and 2 section lattice jib.

Main features:

1Whole diversity configurations, to provide users with more choices

By optimizing the overall layout of calculation and optimization, to achieve the lowest vehicle weight performance maximization case, the operating performance is most advanced in whole Chinese crane industry. And the engine is Hangzhou or Weichai engine as options, selectable 4.5t and 5.5t counterweight two modes of operation, which greatly broadens the scope of the user to select and use.

2Advanced boom technology

5-section telescopic boom, optimized U-shaped cross-section, high-strength steel, crane lifting the performance of the domestic industry has always been a leader. Embedded arm puller reduces the crane is torsion, lateral bending, and the slider and the boom point or line contact phenomena; insert the slider to increase the effective overlap length boom, can effectively avoid local failure stable phenomenon. The Telescopic proprietary technology is to improve active safety telescopic system.

3New LUDV hydraulic system control technology applications, to improve the ability of compound action

System uses independent of flow distribution technology, when the actuator is required when the flow is greater than the pump flow, the system will be proportionally allocated to each flow actuator, which greatly improves the performance of the composite action.

4Double pump confluence fully applied to improve the operating speed

System use the telescopic luffing and hoisting of action to achieve double pump confluence, thereby effectively raising the telescopic luffing, lifting the working efficiency, to meet market and customer needs

5New cooling system, effectively improve the heat exchange rate

Upgraded cooling system, improving vehicle cooling capacity, optimize the structure set deflector wind patterns, adding to the windshield configurations; increased exhaust system to further improve the efficiency of heat exchange cooling system.

6Crane Cab

Ergonomically designed large arc streamlined cab, conforming to ISO standards, beautiful and comfortable, bold and powerful vision. It equipped with LCD monitors, various operating status at a glance.

7Main and auxiliary hoisting mechanism

Built two planetary gear reducer is compact structure, good performance. Normally closed brake, high reliability, high efficiency; dual pump confluence and high pressure automatic variable motors, can effectively improve the lifting speed, increasing the range of operations to achieve heavy low-speed, no-load speed.

8Slewing mechanism

XCMG Using planetary gear and unique back-pressure technology to improve the stiffness of the system, effectively eliminating rotation jitter problems and ensure smooth rotation, and reliable.

9Safety devices

Equipped with a torque limiter, with temperature control and backlight dot matrix LCD color display can be clearly visually displayed as text and graphics crane operation parameters, so that a variety of working conditions at a glance; equipped with an overload protection device and over volume; has height limit, safe direction detection and other security devices; and a lighting device, easy operation at night.

Main specifications:

Category

Item

Unit

Parameters

Dimensions

Overall length

mm

13770

Overall width

mm

2800

Overall height

mm

3570

Wheel base

Axle 12

mm

1470

Axle 23

mm

4105

Axle 34

mm

1350

Track

Front wheel

mm

2304

Rear wheel

mm

2075

Weight

Dead weight in travel state

kg

41000

Axle

Axle 12

kg

15000

Axle 34

kg

26000

Power

Engine rated output


WD615.338

Engine rated torque

kw/(r/min)

276/2200

Max. Travel speed

N.m/(r/min)

1500/(13001600)

Engine Turning Speed

r/min

2200

Travel

Travel speed

Max. Travel speed

km/h

80

Min. travel speed

km/h

23

Turning diameter

Min. tuning diameter

m

24

Min. tuning diameter at boom tip

m

26.8

Min. ground clearance

mm

291

Approach angle

°

17

 Departure angle

°

11

Brake distanceat speed 30km/h

m

≤10

Max. Grade ability

%

40



Main Technical Data for Lifting Operation:



Category

Item

Unit

Parameters

Lifting performance

Max. Total rated lifting load

t

50

Min. rated working radius

m

3

Turning radius at swing table tail

mm

3482

Max. Load moment

Base boom

KN.m

1764

Full-extend boom

KN.m

882

Full-extend boom & jib

KN.m

547

Outrigger extension distance

Longitudinal

m

5.91

Lateral

m

6.9

Lifting height

Base boom

m

11.5

Full-extend boom

m

42.7

Full-extend boom & jib

m

57.6

Boom length

Base boom

m

11.3

Full-extend boom

m

42.7

Full-extend boom & jib

m

57.7

Jib angle

°

01530

Working speed

Boom elevating time

Telescopic

S

40

shrink

S

140

Boom elevating time

Telescopic

S

80

shrink

S

180

Max. Slewing speed

r/min

2

Outriggers speed

Horizontal

Telescopic

S

30

shrink

S

20

Vertical

Telescopic

S

35

shrink

S

30

Hoisting speed

Main winch

Full load

m/min

85

(Single rope 4th layer)

No load

m/min

130


Auxiliary winch

Full load

m/min

85


No load

m/min

130

Outside cabin

dBA

≤122

Inside cabin

dBA

≤90



Photos:

XCMG truck jib crane QY50KA (4).jpg



If you want 50 ton XCMG truck jib crane price, please contact us or send inquiry.

Also we have more specifications, photos, load charts of XCMG QY50KA truck jib crane, waiting for your contact.
