QY20G.5
XCMG
Availability: | |
---|---|
Description:
QY20G.5 is 20 ton XCMG crane truck, it is with XCMG designed and produced truck chassis with full wide cab, drive/steer is 6X4X2.
Its crane operation is mechanical control by five joysticks.
Main features:
1.Boom length by 10.1m ~ 31.6m 10.5m ~ 33m, jib full increase in elongation 1.4m the arm length full over competitors.
2, jib plate material by Q550 upgraded to BS700MC, the cross section Dodecagon, in the long arm of the lifting operation 5 to 13% performance improvement, more than about 3 to 10% of the same industry products.
3, the plug-arm head, reducing boom jitter, lateral bending and torsion improve retractable ride.
4, with heavy weight from 2110 kg to 2510kg, increase 400kg machine lifting performance.
5, the engine than the power in the same product in the same industry, the best dynamic performance of the whole machine.
6, the main and auxiliary lifting wire rope lengthened five meters each
Main specifications:
Dimension | Unit | QY20G.5 |
Overall length | mm | 12400 |
Overall width | mm | 2500 |
Overall height | mm | 3320 |
Weight | ||
Total weight in travel | kg | 26020 |
Front axle load | kg | 6900 |
Rear axle load | kg | 19120 |
Power of engine | ||
Engine model | SC8DK260Q3 | |
Engine rated power | kW/(r/min) | 192/2200 |
Engine rated torque | N.m/(r/min) | 1100/1400 |
Specifications in Travel | ||
Max. travel speed | km/h | 75 |
Min. turning diameter | m | 20 |
Min. ground clearance | mm | 275 |
Approach angle | ° | 16 |
Departure angle | ° | 13 |
Max. grade ability | % | 24 |
Fuel consumption for 100km | L | ≈35 |
Main performance | ||
Max. rated total lifting capacity | t | 20 |
Min. rated working radius | mm | 3000 |
Turning radius at turntable tail | m | 3.385 |
Max. lifting torque | kN.m | 860 |
Base boom | m | 10.06 |
Fully extended boom | m | 32.76 |
Fully extended boom+jib | m | 42.12 |
Longitudinal outrigger span | m | 4.97 |
Lateral outrigger span | m | 5.4 |
Working speed | ||
Boom luffing time | s | 75 |
Boom full extension time | s | 95 |
Max. swing speed | r/min | 3 |
Max. speed of main winch (single rope) | m/min | 100 |
Max. speed of aux. winch (single rope) | m/min | 100 |
Photos:
If you want 20 ton XCMG crane truck price, please contact us or send inquiry.
Also have more specifications, photos, load charts of QY20G.5 crane truck, waiting for your contact.
