XCMG 75 ton heavy lift mobile truck crane XCT75

XCMG 75 ton truck crane model XCT75, Max lift capacity: 75 ton

  • XCT75
  • XCMG
Quantity:


Description:

XCT75 is XCMG designed 75 ton truck crane, it is XCMG G generation truck cranes with Euro 4/5 standard engine.

Main features:

1. Equipped with 5 sections 48m U shape main boom, the leading performance of similar products, any telescopic, boom performance higher;

2. Innovative veneer boom and compact boom-tail structure, lap than the industry's largest, stronger boom bearing capacity;

3. Quantitative valve valve control hydraulic system, micro-movement is good, the minimum speed of rotation to reach 0.5 °/ s, lifting the lowest stable speed of 2.5m / min, accurate lifting;

4. Double pump split flow control technology, operating efficiency;

5. Hydraulic motor independent cooling technology, hydraulic system thermal equilibrium temperature below 80 ℃, high temperature environment, continuous operation without downtime, safe and reliable;

6. XCMG new generation of low-speed high-torque power transmission system, strong power, low fuel consumption, the maximum speed of 90km / h, the maximum climbing capacity of 45%, off-road capability;

7. Rubber suspension, shock absorption effect is good, good guide;

8. Integrated bus panel, equipped with 10.4-inch color display, functional area is clear, convenient and quick;

9. Intelligent conditions of automatic planning technology, users simply enter the key hoisting information, the system automatically recommend the best conditions;

10. Electrical system reliability is higher, waterproof wiring harness layout is reasonable, easy maintenance, long life;

11. Stretch flexible shaft control more convenient, new night lighting, night work more secure;

12. The cab is equipped with three-dimensional air supply is air conditioning;

13. New modeling cab, V-type front face, headlamps use "Hawk eye" bionic technology;

14. The world's first issue, the use of hydraulic recovery system, recycling vehicle braking power, lifting at noon and boom potential energy, effectively reduce vehicle fuel consumption by 15%, to enhance vehicle acceleration performance, climbing ability, long slope braking performance.



Main specifications:

Item

Unit

Parameters

Engine Model


Hangfa/Shangchai

Engine rated output

kw/(r/min)

268/265

Max. travel speed

km/h

90

Min. Turning diameter

m

12

Min. ground clearance

mm

305

Approach angle

°

16

Departure angle

°

13.5

Max. Grand ability

%

45

Max.total lifting capacity

t

75

Min. rated working radius

m

3

Base boom max. load moment

kN.m

3175

Fully extended boom max. load moment

kN.m

1376

Base boom length

m

12.4

Fully extended boom length

m

48

Fully extended boom + Jib length

m

48+17.5

Outrigger longitudinal distance span

m

8.45

Outrigger lateral distance span

m

7.9

Boom luffing time

s

55

Boom elevating time

m/s

145

Boom telescoping time

s

110

Max. slewing speed

r/min

2

Main winch max. speed (no load)

m/min

145

Auxiliary winch max. speed (no load)

m/min

90


Photos:

XCT75 (4).jpg


If you want more information like load chart, photos, price of XCMG 75 ton truck crane XCT75, please contact us or send inquiry.
