XCT8
XCMG
Availability: | |
---|---|
Quantity: | |
Description:
XCT8 is XCMG designed 8 ton truck crane, it is the smallest crane model of XCMG G generation truck cranes. It is with Euro 4/5 standard engine.
Main features:
1.XCT8 with the industry with the tonnage of the longest product 4 25.5m main boom, H-type outriggers, lifting capacity and operating range of a comprehensive industry-leading products at the same level;
2. Innovative veneer boom and compact boom-tail structure, lap than the industry's largest, stronger boom bearing capacity;
3. The industry's first dedicated general-purpose chassis, 6-speed full-synchronous gearbox, single-stage deceleration bridge, the maximum climbing capacity of 35%, the maximum speed of 90km / h, the industry's highest;
4. Quantitative valve valve control open center mechanical control hydraulic system, increase the swing buffer, free sliding function, the system micro-movement is good, faster, more perfect control experience;
5. Rotation minimum stable speed of 0.5 °/ s, lifting the lowest stable speed 3m / min, lifting precision
6. Integrated bus panel, equipped with 5-inch color display, real-time display of working status;
7. Flat head cab, with sleeper, air conditioning three-dimensional air supply.
Main specifications:
Technical specifications of travel state | |||
category | Item | Unit | Data |
Weight | Total weight | kg | 12300/12100 |
Power | Engine Model | \ | YC4E140-42/BF4M2012-14E4 |
Engine output | kw/(r/min) | 103/2600 | 106/2500 | |
Travel | Max. speed | km/h | 90 |
Min. turning diameter | m | 16 | |
Min. ground clearance | mm | 260 | |
Max. grade ability | % | 35 | |
Fuel consumption (100km) | L | 18 |
Technical specifications of crane operation | ||||
category | Item | Unit | Data | |
Lift | Max. lift capacity | t | 8 | |
Max. lift torque | KN | 302 | ||
Min. working radius | m | 3 | ||
Max. lift torque | Base boom | kN.m | 302 | |
Boom length | Base boom | m | 8 | |
longest main boom | m | 25.5 | ||
Speed | Main boom luffing time | s | 28 | |
Main boom extend time | s | 40 | ||
Slewing speed | r/min | 0-3 | ||
lift speed | Main winch no load | m/min | 130 |
Photos:
If you want more information like load chart, photos, price of XCMG 8 ton truck crane XCT8L4, please contact us or send inquiry.
