XCMG 16 ton electric knuckle boom truck crane XCT16

XCMG 16 ton truck crane model XCT16, Max lift capacity: 16 ton
  • XCT16

  • XCMG

Availability:
Quantity:


Description:

XCT16 is XCMG designed 16 ton truck crane, it is XCMG G generation truck cranes with Euro 4/5 standard engine.

Main features:

1.XCT16 4 main boom full extension of 32 meters, the maximum lifting height of 40.5m, the maximum working range of 28.1m;

2. Standard fifth leg, 360 ° full rotation operation;

3. Innovative veneer boom and compact boom-tail structure, lap than the industry's largest, boom bearing capacity stronger;

Quantitative control valve hydraulic system, good micro-movement, the minimum speed of rotation to reach 0.5°/ s, lifting the lowest stable speed of 2.5m / min, accurate lifting;

4. XCMG new generation of low-speed high-torque power transmission system, strong power, low fuel consumption, the maximum speed of 85km / h, the maximum climbing capacity of 48%, lower fuel consumption;

5. Rubber suspension, shock absorption effect is good, good guide;

6. Integrated bus panel, equipped with 5.7-inch color display, functional area is clear, convenient and quick;

7. Intelligent conditions of automatic planning technology, users simply enter the key hoisting information, the system automatically recommend the best working conditions;

8. cab with sleeper, three-dimensional air supply air conditioning;

9. New three-color warning lights, the main sub-winch three full protection, more secure operation;

10. New outriggers operating lights, night work more secure;



Main specifications:

Technical specifications of travel state

category

Item

Unit

Data

Weight

Total weight

kg

23300

Power

Engine Model

\

SC7H245Q4 / WP6.245E40

Engine output

kw/(r/min)

180/2300 | 180/2300

Engine Max. torque

N.m/(r/min)

960/1200-1600 | 900/1100-1700

Travel

Max. speed

km/h

85

Min. turning diameter

m

20

Min. ground clearance

mm

261

Max. gradeability

%

38/48



Technical specifications of crane operation

category

Item

Unit

Data

Lift

Max. lift capacity

t

16

Max. lift moment

KN

730

Min. working radius

m

3

Max. lifting moment

kN.m

730

Boom length

Base boom

m

10

longest main boom

m

32

Boom+Jib

m

40.15

Jib install angle

°

0/15/30

Speed

Main boom luffing time


s

35

Main boom extend time


s

50

Slewing speed

r/min

3

lift speed

Main winch no load

m/min

130

Vice winch no load

m/min

130



Photos:

XCT16 (2).jpg



If you want more information like load chart, photos, price of XCMG 16 ton truck crane XCT16, please contact us or send inquiry.
